Power Strip X CPSX-T1-T6 (EU)

Download Data Sheet

1x powerCON TRUE1 IN – 6x powerCON® TRUE1® TOP OUT - Indoor (IP20)

US version: Power Strip X CPSSX-T1-T6 USA

Power Strip Xtreme (X) is a compact distribution solution for mobile applications. This distribution box is ideally suited for Indoor applications with restricted space / height and harsh usage conditions, for example in theaters, exhibition or similar applications. It also offers a very attractive price point.

Features & Benefits

Extreme robust and safe EASYLEN® housing with leather grain texture
Highly reliable NEUTRIK® powerCON® TRUE1® TOP recepticals for In, Out and Daisy chaining
Flame retardant (UL94-V2) and non-conductive housing material
High mechanical protection (high IK)
Light weight, compact and stackable housing design
Versatile mounting options
Attractive price point

Market & Applications

Markets: Professional video wall / lighting / audio
Mobile application: Festivals, live events , exhibitions / trade shows
Semi-permanent applications: Theaters, studios

Downloads

Drawind Power Strip CPSX-T1-T6 1035598

pdf - 173.91 KB

Drawind Power Strip CPSX-T1-T6 1035598

vnd.dwg - 278.41 KB

BDA 675 V1 - CONTRIK Manual - Power Strip XO and Power Turtle XO- CPVT - 202307

pdf - 1.24 MB

BDA 685 V1 - CONTRIK Manual - Power Strip XO and Power Turtle XO- CPVT - 202307

pdf - 1.24 MB

Technical Information

Product
Input device	1x powerCON® TRUE1® TOP
Output device	6x powerCON® TRUE1® TOP
Daisy chaining	1x powerCON® TRUE1® TOP

Electrical
Contact resistance / protection class	Protection class II
Dielectric strength	0.5 kV / mm
Rated voltage	250V AC
Rated Current	16A (USA: 20A)
Number of electrical contacts	2 + PE
Phases	single-phase

Mechanical
Lifetime	> 5000 Mating cycles per connector
Dimensions	380 x 91.2 x 77 mm
Conductor cross section	2.08 mm²
Weight	1.0 kg
Mounting options	Truss clip, mounting wholes for pegging or suspension
Type of construction	Stackable
